Home Product Presentation BY-PM500W

- Ideal for gaming, streaming, podcasting and more
- Compatible with Android devices, iOS devices with USB-C
  connector and Mac/Windows computers
- Supports wired or wireless operation
- Selectable cardioid and omnidirectional polar patterns
- All-in-one knob for gain & volume control & muting function
- 3.5mm headphone monitoring jack
- 10m wireless operation range (Indoors with obstacles)
- Switchable mono/stereo output mode on wireless receiver
- Rugged integrated microphone desktop stand

Product Introduction

The BOYA BY-PM500W is a revolutionary wireless USB microphone in the industry, offering wired or wireless operation for gamers, streamers, podcasters in a variety of applications. Features with the 2.4GHz wireless technology, BY-PM500W provides up to 10m wireless operation distance and delivers studio-quality audio at the same time. It is much more convenient in long-distance usage scenarios and usage scenarios that require a tidy desktop.

BY-PM500W

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

View All

Product Parameters

Wired Operation

Mic Capsule

14mm Condenser Capsule

Polar Pattern

Cardioid /Omnidirectional

Frequency Response

20Hz-20kHz

Sensitivity

-36dB（0dB=1V/Pa，1kHz 1Pa）

Signal-to-Noise Ratio

80dB

Maximum SPL

110dB

Sampling Rate

48kHz

Bit Rate

24bit

Mic Gain

0~54dB

Working Voltage

5V/100mA

Audio Output Connector

3.5mm Headphone Jack / USB-C Port

Operating Temperature

0℃ to 50℃

Storage Temperature

–20℃ to +55℃

Wireless Operation

Mic Capsule

14mm Condenser Capsule

Polar Pattern

Cardioid /Omnidirectional

Frequency Response

35Hz-18kHz

Sensitivity

-36dB（0dB=1V/Pa，1kHz 1Pa）

Signal-to-Noise Ratio

80dB

Maximum SPL

110dB

Transmission Type

2.4GHz

Modulation

GFSK

Antenna

Dipole Antenna

Operating Range

10m (Indoors with obstacles)

RF Output Power

<10mW

Distortion

<0.05%

Battery Life

8 Hours

Charging Time

1.5 Hours

Battery Capacity

800mAh

Dimensions

TX:226.7×100×100mm / RX:71.6×27.1×10.55mm

Weight

TX:660g / RX:12.5g

Packing List

BY-PM500W Microphone*1

Wireless Receiver*1

USB-C Female to USB-A Male Adapter*1

3.9’(1.2m) USB-A to USB-C Cable*1

3.9’(1.2m) USB-C to USB-C Cable*1

View All

Wired Operation

Mic Capsule

14mm Condenser Capsule

Polar Pattern

Cardioid /Omnidirectional

Frequency Response

20Hz-20kHz

Sensitivity

-36dB（0dB=1V/Pa，1kHz 1Pa）

Signal-to-Noise Ratio

80dB

Maximum SPL

110dB

Sampling Rate

48kHz

Bit Rate

24bit

Mic Gain

0~54dB

Working Voltage

5V/100mA

Audio Output Connector

3.5mm Headphone Jack / USB-C Port

Operating Temperature

0℃ to 50℃

Storage Temperature

–20℃ to +55℃

Wireless Operation

Mic Capsule

14mm Condenser Capsule

Polar Pattern

Cardioid /Omnidirectional

Frequency Response

35Hz-18kHz

Sensitivity

-36dB（0dB=1V/Pa，1kHz 1Pa）

Signal-to-Noise Ratio

80dB

Maximum SPL

110dB

Transmission Type

2.4GHz

Modulation

GFSK

Antenna

Dipole Antenna

Operating Range

10m (Indoors with obstacles)

RF Output Power

<10mW

Distortion

<0.05%

Battery Life

8 Hours

Charging Time

1.5 Hours

Battery Capacity

800mAh

Dimensions

TX:226.7×100×100mm / RX:71.6×27.1×10.55mm

Weight

TX:660g / RX:12.5g

Packing List

BY-PM500W Microphone*1

Wireless Receiver*1

USB-C Female to USB-A Male Adapter*1

3.9’(1.2m) USB-A to USB-C Cable*1

3.9’(1.2m) USB-C to USB-C Cable*1

Put it all away

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

boya pm500w usb microphone

Put it all away

User Manual - BY-PM500W
